ZPG 50.2 M

Model
- submersible waste water pump made of cast iron for portable and stationary (coupling system) purposes
- pump housing, motor housing and impeller made of cast iron, shaft made of stainless steel
- motor winding with thermal winding protection (M-Version only)
- mechanical seal and additional shaft seal
- three-phase or mono-phase motor
- pressure outlet DN 50
- ZPG 50.X M (version A) with mounted float switch
- ZPG 50.X T retrofittable float switch available as an accessory
Application
- pumping of waste water with solid ingredients
- pumping of rainwater and surface water
- portable pump for emergency drainage and drainage of manholes
Scope of delivery
- version M (mono-phase 230 V): pump with 10 m power cable and plug, version WA with mounted float switch
- version T (three-phase 400 V): pump with 10 m power cable
- all pumps without stand feet and outlet bend
- optional coupling system (see accessories)
Article number

13060

Power supply

230 V

Frequency

50 Hz

Power P1

1.250 W

Power P2

750 W

Nominal current

6,0 A

Drive

2800 rpm

Max. temperature

40 °C

Max. flow rate

23,0 m³/h

Head up to

11,9 m

Free passage

45 mm

P-dimensions (WxHxL)

255 mm x 450 mm x 290 mm

features

without float switch
Product name Article number
